ModEco Mobile
Synergy Dream offers the ModEco Mobile mobile charcoal-making retort — a new-generation retort for producing high-quality charcoal directly at the source of the raw material. The model’s main advantage is mobility: the retort is delivered and set up wherever the waste is located or production takes place, completely eliminating the cost of transporting raw material.
The key goals behind this model were autonomous operation, ease of deployment and consistent charcoal quality. The retort works in a cyclic mode: loading, drying, pyrolysis, cooling and unloading of the charcoal. A full cycle takes up to 72 hours even at wood moisture up to 65% — that is up to 10 cycles per month. Typical output is 1.5–1.8 t per cycle (up to 2.0 t per cycle at maximum load).
The retort runs autonomously, with no connection to the power grid (0–0.1 kW optional for auxiliary functions). Pyrolysis gases are directed into the firebox and burned off, providing heat for the process itself — under normal conditions no extra firewood is needed. Thanks to gas afterburning, smoke and odour emissions are kept to a minimum. All retorts are positioned at an equal distance from the firebox, which ensures an identical temperature regime and stable charcoal quality with a carbon content of 82–90%.
As raw material the retort accepts wood of any species, wood waste (offcuts, slabwood, branches, chips), as well as the shells of coconut, almond, walnut and hazelnut. Mechanical deployment usually takes about 2 hours after unloading — no foundation is required. The retort is supplied in a standard 40-foot Open Top container.
| No. | Parameter | Unit | Value |
|---|---|---|---|
| 1 | Raw material loading capacity | m³/batch | up to 10 |
| 2 | Output (charcoal yield) | t/cycle | 1.5–1.8 (up to 2.0) |
| 3 | Full operating cycle | hours | up to 72 |
| 4 | Active cycle (pyrolysis) | hours | up to 24 |
| 5 | Power consumption | kW | 0–0.1 |
| 6 | Operating personnel | person/retort | 1 |
| 7 | Firewood use (ignition only) | m³/day | ≤ 0.8 |
| 8 | Dimensions (L×W×H) | m | 5.0 × 2.4 × 2.6 |
| 9 | Retort weight | t | 4.6 |
| 10 | Start-up preparation time | hours | ~2 |
| 11 | Temperature: firebox | °C | 650–900 |
| 12 | Temperature: retort | °C | ~480 |
| 13 | Temperature: pyrolysis gas | °C | 200–450 |
| 14 | Permissible feedstock moisture | % | up to 60 (opt. ≤ 15) |
| 15 | Feedstock diameter | mm | 10–240 |
| 16 | Feedstock length | mm | up to 4,000 |
| 17 | Container type (transport) | — | 40-ft Open Top |
| 18 | Estimated service life | years | up to 10 |
| 19 | Warranty | months | 12 |
ModEco Mobile suits any production that generates wood waste or nut shells and wants to turn them into high-quality charcoal directly on site. Because the unit comes to the raw material, it removes waste-hauling costs and turns a by-product into a sellable commodity.
| Sector | Description | Key value |
|---|---|---|
| Logging | Processing felling residues right on the plot — the retort is delivered to the harvesting site | Eliminates waste hauling; income on site |
| Sawmills & woodworking | Processing offcuts, slabwood and industrial wood waste | Waste → valuable product; lower costs |
| Nut-shell processing | Coconut, almond, walnut and hazelnut — valuable feedstock for charcoal | Charcoal with 82–90% carbon content |
| Charcoal production | Dedicated charcoal production for barbecue, industrial or domestic use | Scalable — multiple retorts |
From waste to profit. The same advantage applies in every sector: material that would otherwise be a disposal cost becomes finished charcoal for sale in bulk or big bags. The unit can be run by a single operator, and as volumes grow you can add more retorts — without stopping production.
